CDK 10SA … 2500SA Air Dryers

CDK 10SA … 2500SA Air Dryers: Air and Water Cooled Options

Move to Performance – Move to Quality – Move to Artic

CDK 10SA … 2500SA Air Dryers – Air and Water Cooled

Discover the epitome of high-efficiency air dryer solutions with the CDK 10SA … 2500SA Series. Designed and manufactured in Thailand, these stainless steel cycling refrigerated air dryers leverage a patented 3-in-1 heat exchanger and unique separator design to deliver clean, dry air for large-capacity applications.

Boasting flow rates from 1.7 to 423.7 m³/min, a steady dew point of 3 °C, and support for pressures up to 16 bar, CDK air dryers combine durability and innovation. Whether you opt for air-cooled or water-cooled models, you’ll benefit from robust construction, eco-friendly freon compressors, and consistent performance.

Why Choose CDK 10SA … 2500SA Air Dryers?

Additionally, by offering both air-cooled and water-cooled models, the CDK Series grants you the flexibility to select the perfect match for your specific environment and operational requirements.

Key Highlights

CDK 10SA … 2500SA Air Dryers are engineered for reliability and built to tackle demanding industrial needs. Equipped with compressors from Copeland, Hitachi, or Mitsubishi and protected by anti-corrosion coatings, these dryers excel under diverse conditions. Their intelligent design ensures moisture and contaminants are effectively removed from compressed air, resulting in enhanced packaging and pneumatic operations. Additionally, by offering both air-cooled and water-cooled models, the CDK Series grants you the flexibility to select the perfect match for your specific environment and operational requirements.

Reliable Separator Design

Experience unmatched consistency and minimal downtime, thanks to a unique separator system that handles demanding flow rates.

Patented 3-in-1 Exchanger

A cutting-edge design that consolidates core processes—cooling, condensing, and moisture separation—into one compact, highly efficient unit.

Eco-Friendly Operation

Utilising approved freon gases, these dryers reduce energy consumption and environmental impact.

Stainless Steel Durability

Corrosion-resistant components stand up to high pressures and harsh conditions for an extended service life.

Benefits

High Performance

Enjoy consistent results with the plate-to-plate heat exchanger and separator, ensuring a steady dew point of 3 °C under pressures up to 16 bar.

Energy Efficiency

A patented high thermal efficiency exchanger minimises power consumption, reducing operating costs without compromising on output.

Innovative Design

The 3-in-1 configuration optimises performance, space usage, and moisture removal, making these dryers a perfect fit in both large and compact setups.

Long-Lasting Construction

Solid build techniques and stainless steel components, along with blue fin coatings on condenser coils, resist corrosion and maintain top performance even in demanding environments.

Versatility

Choose between air-cooled or water-cooled versions to adapt to your available resources, ambient temperatures, and other site-specific conditions.

Precision Control

CAREL® control panels offer user-friendly monitoring and data access, giving you the power to customise settings and maintain stable operating conditions.

Cost-Effective Operation

Achieve high performance at a reasonable price, with reliable functionality that cuts down on long-term maintenance and energy expenses.

Environmental Safety

Featuring eco-friendly refrigerants and robust anti-corrosion coatings, these dryers protect both your investment and the surrounding ecosystem.

Professional Support

With decades of industry expertise, our team provides comprehensive aftercare and troubleshooting services to keep your system running smoothly.

Additional Features

Durability and Construction

Stainless steel, corrosion-resistant design suitable for high pressures up to 16 bar.
Blue fin coatings on condenser coils add a layer of protection against harsh conditions.

Easy Maintenance

Spacious internal galleries simplify cleaning and reduce the risk of blockages, minimising downtime.
Streamlined design allows quick access to key components for inspections or repairs.

Certified Standards

UL, CE, and PED certifications guarantee compliance with strict safety and performance regulations.
Eco-friendly freon gases reduce environmental impact, supporting global sustainability initiatives.

Performance Metrics

Capable of maintaining a dew point of 3 °C at high inlet temperatures (up to 65 °C).
Innovative 3-in-1 heat exchanger ensures optimal thermal transfer and moisture removal.

Optional Configurations

Air-cooled or water-cooled setups provide adaptability to site conditions.
Multiple models (26 in total) mean you can find the perfect capacity for your operation.

GET A QUOTE

The CDK 10SA … 2500SA Air Dryers deliver a powerful fusion of reliability, durability, and innovation. Whether you select an air-cooled or water-cooled version, each model is designed to meet demanding industrial requirements while conserving energy and reducing environmental impact. From the patented 3-in-1 heat exchanger to the user-friendly CAREL® control panels, every feature enhances your compressed air system’s efficiency.

Specifications
FAQ

Banded Table

Model	Power (kW)	Dimensions (mm)	Connection	Weight (kg)
CDK – 10SA	1.7	382 x 502 x 480	1/2″	38
CDK – 15SA	2.2	382 x 502 x 408	3/4″	40
CDK – 20SA	3.4	393 x 723 x 650	3/4″	65
CDK – 30SA	5.4	393 x 723 x 650	1″	69
CDK – 40SA	6.9	404 x 875 x 761	1 1/2″	92
CDK – 50SA	8.5	404 x 875 x 761	1 1/2″	101
CDK – 60SA	10.1	451 x 1190 x 882	1 1/2″	115
CDK – 75SA	13.7	451 x 1190 x 882	2″	135
CDK – 100SA	18.7	451 x 1190 x 882	2″	145
CDK – 150SA	28.7	588 x 1204 x 1005	2 1/2″	198
CDK – 175SA	34.9	588 x 1204 x 1005	2 1/2″	208
CDK – 200SA	37.4	588 x 1204 x 1005	3″	225
CDK – 250SA	44.9	588 x 1204 x 1005	3″	256
CDK – 300SA	53.6	1004 x 1560 x 1615	4″ FL	380
CDK – 350SA	59.8	1004 x 1560 x 1615	4″ FL	400
CDK – 400SA	76	1004 x 1560 x 1615	5″ FL	450
CDK – 500SA	89.7	1004 x 1560 x 1615	5″ FL	510
CDK – 600SA	110.9	1200 x 2200 x 1900	6″ FL	930
CDK – 700SA	119.6	1200 x 2200 x 1900	6″ FL	1050
CDK – 800SA	152	1200 x 2200 x 1900	6″ FL	1120
CDK – 1000SA	179.4	1200 x 2860 x 1900	8″ FL	1260
CDK – 1200SA	211.8	1200 x 2860 x 1900	8″ FL	1580
CDK – 1500SA	230.5	1200 x 3200 x 2050	10″ FL	2200
CDK – 2000SA	355.1	1200 x 5000 x 2050	12″ FL	2400
CDK – 2500SA	423.7	1200 x 5000 x 2050	12″ FL	3100

How do air dryers work and are they more environmentally friendly?
Air dryers remove moisture from compressed air by cooling it, causing water vapor to condense and drain out before the air enters downstream equipment. Air-cooled models in particular use less energy than many traditional methods, making them a sustainable option for a variety of applications.

What are some common misconceptions about air dryers?
A frequent misconception is that air dryers only remove moisture. In reality, they also help filter out contaminants to ensure cleaner air. Another myth is that all air dryers are noisy; modern designs like the CDK Series operate quietly and efficiently.

How do I know the air dryer will last?
Our dryers feature a robust, stainless steel build, corrosion-resistant components, and advanced separator technologies—all contributing to a long operational life, even under demanding conditions.

Is the air dryer energy efficient?
Yes. The CDK Series leverages a patented high thermal efficiency exchanger that reduces energy use while delivering consistent performance.

Can I trust its reliability at my flow rates?
Absolutely. UL/CE/PED-certified separators offer reliability at diverse flow rates, backed by proven performance data.

Will this product fit my air flow needs?
With capacities ranging from 1.7 to 423.7 m³/min, you can easily select a model that matches your specific operational requirements and environment.

Does it require frequent maintenance?
Not at all. Ample internal galleries and simplified designs minimise blockage risks, making routine upkeep straightforward and less frequent.

What if I need support after purchase?
Our professional expertise and dedicated support team ensure prompt assistance and comprehensive aftercare—day or night.

Ready to boost performance and protect your valuable equipment? Order your CDK Air Dryer today and experience the difference in long-term operational excellence.
